1-Inch CMOS Sensor
6K Video & 20MP Photo
12km Video Transmission
Obstacle Sensing in 3 Directions
40-Min Max Flight Time

[keyfeatures]

Overview
Specs
In the box
Videos
Download

Note ! ! !
Autel Robotics EVO Lite+ Standard Bundle is currently sold out, please choose Autel Robotics EVO Lite Plus Premium Bundle, the more accessories to help with aerial photography!

Autel Robotics EVO Lite Plus Premium Bundle👉https://www.autelpilot.com/products/autel-robotics-evo-lite-plus-drone-premium-bundle

Autel EVO Lite+ Drone

The Autel EVO Lite+ Drone is specially equipped with an intelligent moonlight algorithm, which works with the 20MP camera and 1" CMOS sensor to capture vibrant nighttime details, even at high ISOs. Whether you shoot hi-res stills or HDR video up to 6K resolution, the Lite+ allows for manual control over exposure and depth of field, letting you adjust the aperture between f/2.8 to f/11. The Lite+ can also automatically balance overexposure and underexposure, ensuring your images and videos remain clear.

Piloting the EVO Lite+ to capture this footage is made to be comfortable and intuitive with an included gamepad-style controller that uses your existing smartphone with the Autel SkyLink and Fly apps. As you fly, you can view what the drone sees from up to 7.4 miles away in 1080p resolution utilizing dual-band connectivity. You can even view what's around the Lite+ by using the wide-angle cameras that are utilized for obstacle avoidance.

1" CMOS

Imaging Sensor

20MP

Photos

6K/30fps

HDR Video

3-Axis

Mechanical Gimbal

40 Mins

Flight Time

7.4 Miles

Transmission Distance

Compact & Foldable Design

The propellers and arms of the Autel EVO Lite+ conveniently fold into a tight package that makes traveling with your drone easier.

1" CMOS Sensor with 20MP Camera

Autel drone EVO Lite+ is equipped with a 1-inch image sensor, a 20MP camera, and a large 2.4μm pixels that can record 6K/30fps and 4K/60fps video. In addition, the Autel EVO Lite+ Drone is specially equipped with an intelligent moonlight algorithm that can capture crisp, vibrant details at night with low noise — even when the ISO is cranked up high.

Adjustable Aperture From f/2.8-f/11

Flex your creativity with an adjustable aperture from f/2.8-f/11, giving you the ability to alter exposure and depth of field in imaginative ways that show off your unique artistic style.

1" CMOS 20MP

Imaging Sensor

2.4μm（ Bin2）

Pixel size

6K/30FPS Video

8-bit HDR

3-Axis

Mechanical Gimbal

RGGB Sensor

Color Filter

F2.8~F11

Adjustable Aperture

Take Back The Night.

Capture the allure of the world, even as it darkens. Thanks to Autel's intelligent moonlight algorithm, the EVO Lite+ can capture vibrant nighttime details, even at high ISOs.

HDR: Darker Shadows. Brighter Highlights.

With HDR on, the EVO Lite+ drone wiill snap several photos at different exposures and automatically stitch them together- resulting in a photo with more contrast and dynamic range.

Restore Natural Colors

Automatically balance overexposure and underexposure when shooting scenes with too much contrast, producing clearer images with more layers.

Defog Mode

Whether you're flying over a gloomy hilltop at dawn or hovering at the base of a waterfall, the EVO Lite+ enable you cut through the haze with a fog penetration function that automatically adjusts the camera's vibrance settings to make your footage look crisp and clear.

Cinematic Shots With A Single Click

Create dramatic, professional-level shots at the touch of a button with four automatic shooting modes. Add a soundtrack and filters in the Autel Sky app to make your video even more epic, allowing you to produce unforgettable results whether you're a veteran pilot or completely new to the drone game.

SkyPortrait - Blur the background automatically for additional cinematic effect/Portrait

Take the ultimate selfie with the press of a single button. When engaged, SkyPortrait will raise your EVO Lite into the air where it will snap a photo, automatically adjusting the lens to include everyone. You can even have the Lite automatically blur out the background to focus only on you and your friends for additional cinematic effect/Portrait.

Dynamic Track 2.1: Master Subject Tracking

Recruit your EVO Lite+ drone to automatically follow any person, animal, or vehicle so you can focus on your activities while your EVO Lite+ handles the cinematic side.

MovieMaster: Quick And Easy Movies

Apply your favorite templates from the Autel Sky app for quick and easy movie-making, allowing you to drastically reduce the tedious editing process so you can share your creations in minutes.

Snap And Share In Seconds

Done shooting? Simply place your smartphone close to the EVO Lite+ to upload photos and videos at a speedy rate of 160Mbps using the Autel Sky app.

SonarSound: Hear Everything

Record voices and ambient sounds on the ground through the smartphone, allowing you to bring your videos to life even when your drone is miles above.

Fly Safer With 3-Way Obstacle Avoidance

Not commonly seen in drones of this size, the EVO Lite+ 6K drone incorporates an advanced obstacle avoidance system to keep it safe while flying. With 3-way binocular vision sensors that enable the drone to perceive obstructions in front of it, behind it, and below it. If anything comes into the Lite's path, it will automatically brake and hover to avoid a collision.

12KM 2.7K/30FPS Video Transmission

Autel EVO Lite+ drone features Autel's most advanced Autel SkyLink image transmission system yet, delivering an ultra-smooth, clear, and reliable image feed while flying farther. The EVO lite+ has a video transmission distance of up to 7.4miles (12 km), the transmission quality of 2.7K/30FPS.

2.4/5.2G/5.8Hz Three Frequency

Reliable Signal, Smooth Flight

The EVO Lite+ drone supports 2.4/5.8GHz three-frequency communication and automatically switches to the best channel with the lowest interference in real-time. This significantly improves the aircraft's anti-interference ability in challenging environments, increasing flight safety.

40 Minutes Flight Time

More Battery. More Time. More Creativity.

The EVO Lite+ can fly continuously for 40 minutes, which means plenty of time to experiment with creative angles and dream up inventive shots.
NEW PERSPECTIVES. NEW POSSIBILITIES.

Adjustable Aperture From f/2.8-f/11

1" CMOS Sensor 20MP Photo & 6K/30fps Video

40-Min Max Flight Time

10km 2.7K Video Transmission

Multiple Automatic Flight Modes

Wide-Angle Obstacle Avoidance System

From USD $1549

Lite Aircraft

Takeoff weight	820g
Dimensions (including blades)	Folded: 210×104×85mm Unfolded: 430×517×85mm
Wheelbase	368mm
Max ascent speed	8m/s (sport), 5m/s (normal), 3m/s (stable)
Max descent speed	4m/s (sport), 3m/s (normal), 2m/s (stable)
Max Level Flight Speed (no wind, near sea level)	19m/s (sport), 10m/s (normal), 5m/s (stable)
Max Takeoff Altitude	4000m
Max Flight Time (no wind)	40min
Max Hovering Time (no wind)	38min
Max Flight Distance (no wind)	24km
Max Wind Resistance	Level 7
Max Tilt Angle	33°(movement), 25°(normal), 25°(stable)
Max Angular Velocity	200°(movement), 120°(normal), 60°(stable)
Operating Temperature	-10°C ~ 40°C
Operating frequency	2.400-2.4835GHz 5.725-5.850GHz 5.150-5.250GHz
Transmission Power (EIRP)	FCC:≤30dBm
GNSS	GPS
Hovering Accuracy	Vertical:±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal:±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning);
Built-in storage	6GB
SD storage	Max. support 256GB（UHS-3 rating required）

Gimbal

	Lite	Lite+
Stabilization	4-axis (horizontal/vertical/tilt/rotation shooting)	3-axis
Mechanical Range	Pitch: -135°~45° Roll: -45°~45° Yaw: -90°~90° Rotate: -400°~400°	Pitch: -135°~45° Roll: -45°~45° Yaw: -90°~90°
Controllable Range	Pitch: -90°~30° Yaw: -80°~80° Rotate: -360°~360°	Pitch: -90°~30° Yaw: -80°~80°
Max Control Speed (pitch)	30°/s	30°/s
Angular Vibration Range	±0.003°	±0.003°

Perception System

Forward	Accurate measurement range: 0.5~18m Effective sensing speed:<12m/s FOV: horizontal<70°, vertical <88°
Backward	Accurate measurement range：0.5~18m Effective sensing speed：<12m/s FOV：Horizontal<40°,Vertical<30°
Downward	Accurate measurement range: 0.5~22m Visual hovering range: 0.5~40m FOV: horizontal<40°, vertical <30°
Operating environment	Forward, backward: Surface with clear pattern and adequate lighting(lux> 15) Downward: Surface with clear pattern and adequate lighting(lux> 15); Detects diffuse reflective surfaces(>20%) (walls, trees, people, etc.)

Camera

	EVO Lite	EVO Lite+
Sensor	CMOS: 1/1.28 inch Effective pixels: 50M Pixel size: 1.22μm*1.22μm	CMOS: 1 inch Effective pixels: 20M Pixel size: 2.4μm*2.4μm
Lens	FOV: 85° Equivalent focal length: 23mm Aperture: f/1.9 Focus range: 0.5m ~ ∞ Focus mode: PDAF+CDAF/MF	FOV: 82° Equivalent focal length: 29mm Aperture: f/2.8 ~ f11 Focus range: 0.5m ~ ∞ Focus mode: CDAF/MF
Shooting mode	Automatic mode (P gear): EV adjustable, ISO/Shutter automatic Manual mode (M gear): ISO/Shutter adjustable, EV not adjustable Shutter priority (S file): Shutter/EV adjustable, ISO automatic	Automatic mode (P gear): EV is adjustable, Shutter/Aperture is not adjustable, ISO is automatic or adjustable. Manual mode (M gear): ISO/Shutter/Aperture is adjustable, EV is not adjustable. Shutter priority (S file): Shutter/EV adjustable, Aperture automatic, ISO automatic or adjustable. Aperture priority (A gear): Aperture/EV adjustable, Shutter automatic, ISO automatic or adjustable.
ISO range	Video: ISO100 ~ ISO6400 Photo: ISO100 ~ ISO6400 Night scene mode: ISO up to 64000	Video: ISO100 ~ ISO6400 Photo: ISO100 ~ ISO6400 Night scene mode: ISO up to 64000
Shutter speed	Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates	Photo mode: 1/8000 ~ 8s Other: 1/8000 ~ 1/frame rates
Portrait blur	Real-time image transmission portrait blur and photo portrait blur	Real-time image transmission portrait blur and photo portrait blur
Defog mode	Support	Support
Zoom Range	Digital zoom: 1 ~ 16 times Lossless zoom: 4K: 2 times; 1080p: 4 times Note: 4K: more than 2 times the digital, the following is lossless 1080P: more than 4 times the digital, the following is lossless	Digital zoom: 1 ~ 16 times Lossless zoom: 4K: 1.3 times; 1080p: 3 times Note: 6K: Digital zoom 4K: more than 1.3 times the digital, the following is lossless 1080P: more than 3 times the digital, the following is lossless
Photo format	JPG / DNG / JPG+DNG	JPG（10bit） / DNG(12bit) / JPG+DNG
Photo resolution	50MP：8192x6144（4:3） 12.5MP（default）：4096x3072（4:3） 4K：3840x2160（16:9）	5472x3648 (3:2，default) 5472x3076 (16:9) 3840x2160 (16:9)
Photo shooting mode	Single shot Burst shooing: 3/5 Auto exposure bracketing(AEB): 3/5 shots Interval: 2s/3s/4s/5s (default)/6s/.../60s (DNG min 5s) HDR imaging: 8192x6144/4096x3072/3840x2160 HyperLight: 8192x6144/4096x3072/3840x2160	Single shot Burst shooing: 3/5 Auto exposure bracketing(AEB): 3/5 shots Interval: 2s/3s/4s/5s (default)/6s/.../60s (DNG minimum 5s) HDR imaging: 5472x3648/3840x2160 HyperLight: 5472x3648/3840x2160
Video coding format	H265/H264	H265/H264
Video resolution	3840x2160 p60/50/48/30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p120/60/50/48/30/25/24 HDR: 3840x2160 p30/25/24 2720x1528 p30/25/24 1920x1080 P60/50/48/30/25/24	5472x3076 p30/25/24 3840x2160 p60/50/48/30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p120/60/50/48/30/25/24 HDR: 3840x2160 p30/25/24 2720x1528 p60/50/48/30/25/24 1920x1080 p60/50/48/30/25/24
Max bitrate	120Mbps	120Mbps
Timelapse	Original image:3840*2160，JPG/DNG Video: 4K P25	Original image：54723076/38402160，JPG/DNG Video：5.4K/4K P25
Panorama	Horizontal/Vertical/Wide-angle/Spherical Original image: 4096*3072，JPG/DNG	Horizontal/Vertical/Wide-angle/Spherical Original image: 5472*3648, JPG/DNG
Supported file system	Fat32、exFat	Fat32、exFat
Video format	MP4/MOV	MP4/MOV
WIFI transfer	20MB/s	20MB/s

Remote controllor and image transmission

Operating frequency	2.400-2.4835GHz 5.725-5.850GHz 5.150-5.250GHz
Max transmission distance (unobstructed, free of interference)	FCC：12km
Operating temperature	0°C ~40°C
Transmission power (EIRP)	FCC：≤30dBm
Battery capacity	3930mAh
Max battery life	~ 3.5h (when connected to a mobile phone) ~ 2.5h (when not connected to mobile phone)
Interface type	Type C
Transmission system	Autel SkyLink
Realtime transmission quality	Transmission distance<1km：2.7K 30fps Transmission distance>1km：720P 30fps
Transmission bitrate	90Mbps
Transmission delay	≤200ms

Adapter

Input	100-240V/50-60HZ
Output	12.75V==5A
Rated power	63.75W

Aaircraft Battery

Capacity	6175mAh
Voltage	11.13V
Max charging voltage	12.75V
Battery Type	Li-Po 3S
Energy	68.7Wh
Charging temperature	5~45℃
Single battery charging time	90min
Max charging power	78W

App

Mobile App	Autel Sky
Mobile system required	iOS 12.0 and above Android 8.0 and above

Autel Evo Lite + Unboxing

Incredible Iceberg in Greenland: Shot on EVO Lite+

Shot on EVO Lite+
Autel Sky

Built to accompany the EVO Nano and EVO Lite, the Autel Sky app enables beginners and veterans alike to get professional-level shots at the touch of a button with four automatic shooting modes (flick, rocket, fade away, and Orbit). Make your shots even more unique using the app‘s time-lapse, panoramic, tracking, and portrait modes. Done shooting? Instantly upgrade your footage from impressive to unforgettable using the app's vast selection of ready-made video templates and soundtracks. From flying to shooting to editing, Autel Sky is a must-have companion for any videographer hoping to make an impact.

Compatible with：EVO Nano, EVO Nano+, EVO Lite, EVO Lite+
